Select Your Vapor Tight High Bay
Our 4V02 LED High Bay Vapor Tight Luminaires are available in an impressive range of models. We've broken them down to two categories: without motion sensor and with motion sensor. Find the best model for you or your customer's application below.
Featured 4V02 Models
These luminaires are for applications that need the best in durability and illumination for challenging environments. Their color and wattage selectable functions make them our most flexible high bay vapor tight solution.
-
4V02-180W Selectable 4ft LED Linear Vapor Tight High Bay
- 180/155/135/105W Selectable
- 15,750 to 27,000 lumens
- 3500K/4000K/5000K CCT Selectable
- 110° Beam Angle
- 120-277VAC
Additional Options:
Clear or frosted lens
Emergency driver
Housing color (special order)
120-347VAC (special order)
Motion sensor (special order)4V02-180W Selectable 4ft LED Linear Vapor Tight High Bay
- 15,750 to 27,000 lumens
- 3500K/4000K/5000K CCT Selectable
- 110° Beam Angle
- 120-277VAC
Additional Options:
Clear or frosted lens
Emergency driver
Housing color (special order)
120-347VAC (special order)
Motion sensor (special order) -
4V02-155W Selectable 4ft LED Linear Vapor Tight High Bay
- 155/135/125/100W Selectable
- 15,000 to 21,700 lumens
- 3500K/4000K/5000K CCT Selectable
- 110° Beam Angle
- 120-277VAC
Additional Options:
Clear or frosted lens
Emergency driver
Housing color (special order)
120-347VAC (special order)
Motion sensor (special order)4V02-155W Selectable 4ft LED Linear Vapor Tight High Bay
- 15,000 to 21,700 lumens
- 3500K/4000K/5000K CCT Selectable
- 110° Beam Angle
- 120-277VAC
Additional Options:
Clear or frosted lens
Emergency driver
Housing color (special order)
120-347VAC (special order)
Motion sensor (special order)
DETAILS
Introducing the 4ft Field-Selectable High Bay Vapor Tight Luminaire, your go-to solution for high-ceiling applications where moisture, water, dust, or corrosion is a concern. This completely sealed LED fixture is built to withstand tough environments like barns, car washes, factories, marinas, and other locations where the light will be exposed to water, humidity, excessive dust, or corrosive salt. It's also NSF-rated and shatterproof, making it perfect for use in food processing plants and commercial kitchens.
Our selectable models offer the flexibility of choosing from 4 power and 3 color temperature options during installation, allowing for lighting levels and tones to be selected at install to meet the needs of different zones within a facility or across separate buildings. These selectable models are also an ideal option for bulk buying and stocking.
We also offer fixed wattage/CCT-selectable options in the 100W and 150W models, if you just need the color selection functionality.
- IP67, IK10, and NEMA 4X rated housing
- NSF certified
- Suitable for use in temperatures down to -40°F
- Choose from a range of fixed wattage models, or order a wattage-selectable model for the ability to set the best lighting level for each of your spaces during install
- The same is true of color temperature: Go with a fixed 3500K, 4000K, or 5000K CCT, or choose CCT-selectable
- Surface-mount installation is quick thanks to stainless steel spring clips. You can alternately suspension mount this luminaire (chains not included)
- Available with or without built-in motion sensor and/or emergency battery backup
- This luminaire is DLC 5.1 Premium Listed as a High-Bay Luminaire for Commercial and Industrial Buildings, qualifying it for higher rebates
With its worry-free and cost-effective features, our 4ft LED Vapor Tight High Bay Luminaire is the perfect lighting solution for all of your tough environments.
KEY SPECIFICATIONS
Lumens Packages |
Selectable 155W/135W/125W/100W Model: Up to 21,700 lumens Selectable 180W/155W/135W/105W Model: Up to 27,000 lumens Also available: 75W Model: 10,500 lumens 100W Model: 14,000 lumens 150W Model: 21,000 lumens 180W Model: 25,200 lumens 210W Model: 30,000 lumens |
System Efficacy | Up to 150 lm/W |
CRI | > 80 |
Beam Angle | 110° |
Dimming Capability | 0 to 10V |
CCT | Selectable-Wattage Models: 3500K/4000K/5000K Selectable Also available: Fixed Wattage Models: 3500K, 4000K, or 5000K 100W and 150W Fixed Wattage Models: Selectable 3500K/4000K/5000K also available |
Projected Lifetime | 54,000 hours |
Enclosure Rating | IP67, IK10, NEMA 4X |
Input Voltage | 120-277VAC standard, 120-347VAC by special order. 150W model also available in 277-480VAC. |
Dimensions | 49.88” x 10” x 4.07” |
Warranty | 5 Years |
Certifications | ETL, NSF, NEMA 4X, FCC. CCT-Selectable, clear-lens models are DLC Premium. |
DLC Listing Primary Use Category | CCT-Selectable, Clear Lens models: High-Bay Luminaires for Commercial and Industrial Buildings |
*IES file links on this page may not contain an IES file for every available configuration of the model.
