FL06 Series Flood Light

FL06 Series Flood Light

Illuminate outdoor spaces with powerful, energy-efficient lighting. The FL06 Series delivers high-quality illumination with adjustable output, ensuring versatility for a wide range of commercial and industrial applications.

  • Selectable Wattage from 17W to 250W
  • Selectable CCT 3000K/4000K/5000K
  • 0-10V Dimmable
  • Photocell Compatibility
  • Durable Die-Cast Aluminum Housing
  • Multiple Mounting Options: Knuckle, Trunnion, Slipfitter
  • 5-Year Warranty
DLC Premium UL Listed Wattage Selectable CCT Selectable 277-480V 0-10V Dimming IP-65 Rated Enclosure IK-08 Impact Rating
View full details

DETAILS

High Adaptability Meets High Efficiency

Built for sign lighting, building facades, parking areas, and security lighting, FL06 flood lights provide consistent, high-efficiency performance in any environment.

Adjustable Brightness & Color

Easily adjust output to fit the space while maintaining high efficacy up to 181 lm/W. To increase adaptability even further, this light offers dimming and daylight-sensing control options.

Rugged, Weather-Resistant Design

An IP65-rated, die-cast aluminum housing with a tempered glass cover ensures long-term durability against harsh conditions.

Multiple Mounting Options

Choose from knuckle, trunnion, or slipfitter mounts for flexible installation on poles, walls, or building exteriors.

Applications

Ideal for sign lighting, facades, parking lots, security lighting, and general outdoor illumination where powerful, reliable lighting is essential.

Quick-Ship FL06 Flood Lights

DOWNLOADS

Download Spec Sheet Data Sheet - FL06 Series LED Flood Light

Download Spec Sheet Installation Guide - FL06 Series LED Flood Light

Download Spec Sheet IES Files (.zip) - FL06 Series LED Flood Light

KEY SPECIFICATIONS

Wattage & Lumens 30W Selectable (17/25/30W), 2,805 to 5,350 lumens
63W Selectable (36/50/63W), 5,760 to 11,200 lumens*
108W Selectable (63/90/108W), 9,950 to 19,050 lumens*
155W Selectable (90/125/155W), 13,500 to 27,150 lumens*
250W Selectable (125/150/200/250W), 19,250 to 45,250 lumens*

* Typically stocked
System Efficacy 150 to 181 lm/W
CRI 70
Dimming Capability 0 to 10V
CCT 3000K/4000K/5000K Selectable
Input Voltage 120-277VAC, 50-60Hz (277-480VAC by special order)
Beam Angle 30-155W: 7H×7V
250W: 6H6V (Standard) or 4H4V (Special Order)
Mounting Knuckle or Trunnion (30W, 63W Models)
Trunnion or Slipfitter (108W, 155W, 250W Models)
IP Rating IP65
IK Rating IK08
Certifications DLC Premium, UL
Warranty 5 Years

*IES file links on this page may not contain an IES file for every available configuration of the model.
