SB03 Series Solar LED Sign Light
SB03 Series Solar LED Sign Light
Designed for signage and billboards in low-access locations, this LED fixture is solar, offers dependable illumination, and comes in two size options.
With high efficacy, selectable color temperature, and intelligent dimming control, it’s built to maximize visibility and energy efficiency for off-grid applications.
The durable housing and quick charging solar panel ensure reliable, maintenance-free performance - even in remote or weather-exposed environments.
DETAILS
Fast-Charging Solar Signage Light
- Quick charge in just 3 to 4 hours of daylight
- Auto-dimming allows for extended use, up to 3 nights on 1 charge
- Anti-glare for pedestrian and vehicle driver safety
- Easy installation with included surface mount bracket or optional adjustable clamp-mount brackets
- Airplane-grade aluminum frame for durability
- High-output mono-crystalline solar panel
- Reach out for a quote on additional lengths, from 1ft to 6ft
SB03 Solar Slgn Light Quick Ship Models
When to Specify This Sign Light Model
- ✔ Monument and wayfinding signs
- ✔ Building graphics and storefront signage
- ✔ Applications near walkways or roadways where glare control is important
- ✔ Locations with limited daily sun exposure (3–4 hour recharge window)
- ● Billboard lighting applications up to 8ft height
- ◇ More color-accurate rendering is needed for logos, graphics, or advertising
- ◇ The project involves continuous façade illumination or wall-washing
- ◇ The project requires extended high-output runtime into early morning hours
- ◇ Ideal for locations with limited solar charge or all-night visibility requirements
- ◇ The sign has an irregular face or no accessible direct-mount surface
- ◇ Billboard height exceeds 8ft
- ◇ Installations are located along highways or high-speed traffic corridors
- ◇ North-facing signage requires higher output or wider beam distribution
Sizing Guide: Quick Ship Options
| Model | 30" Sign Width |
48" Sign Width |
72" Sign Width |
96" Sign Width |
Or Minimum of One Fixture Per: |
|---|---|---|---|---|---|
| SB03-04 (2ft fixture) | 1 | — | 2 | 3 | 38" |
| SB03-08 (4ft fixture) | — | 1 | — | 2 | 78" |
For signs wider than 96", consult the minimum coverage column above to determine additional fixture requirements. Dark sign backgrounds or high ambient light environments may require increased fixture density for optimal visibility.
Provide a few project details and we’ll recommend the appropriate fixture configuration, spacing, and series.
DOWNLOADS
*IES file links on this page may not contain an IES file for every available configuration of the model.
KEY SPECIFICATIONS
| Lumens Package | 2W: 400 lumens 4W: 800 lumens* 6W: 1,200 lumens 8W: 1,600 lumens* 10W: 2,000 lumens 12W: 2,400 lumens * Typically stocked |
| System Efficacy | 200 lm/W |
| CRI | 80 |
| CCT | 3000K/4000K Selectable |
| Beam Angle | 90° |
| Controls | Timer dimming |
| Charging Time | 3-4 hours* |
| Operating Time | Time Control: 2-3 Days* |
| Battery |
2W: 7.4V/2.6AH 4W: 7.4V/5.2AH 6W: 7.4V/7.8AH 8W: 7.4V/10.4AH 10W: 27.4V/15.6AH 12W: 7.4V/20.8AH |
| Solar Panel | Mono-Crystalline Bifacial Solar Panel 2W: 12V/10W 4W: 12V/20W 6W: 12V/30W 8W: 12V/40W 10W: 12V/50W 12W: 12V/60W |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Battery Charging Temperature | 0°C to 45°C (32°F to 113°F) |
| Mounting | Surface Mount, Adjustable Clamping Bracket Mount |
| Warranty | 3 Years |
*Performance based on ideal conditions - solar lights are heavily affected by sunlight levels temperatures, snow, dirt, and other conditions.
